Description
Annexin V-PE/TR/DAPI Apoptosis Kit
The Annexin V-PE/TR/DAPI Apoptosis Kit (AKES064) detects apoptosis in suspension and adherent cell samples by combining a PE/TR-conjugated Annexin V reagent with DAPI. Annexin V binds phosphatidylserine (PS) exposed on the outer leaflet of the apoptotic cell membrane in a calcium-dependent manner, while DAPI enters cells with compromised membranes to stain DNA. Using both stains together lets researchers distinguish cells at different apoptotic stages by flow cytometry or fluorescence microscopy.
Annexin V is a member of the annexin protein family that binds phosphatidylserine (PS) in a calcium-dependent manner. In apoptotic cells, PS is present on the outer leaflet of the cell membrane, where Annexin V binds it specifically. This binding property makes Annexin V a marker of apoptosis that can be applied to suspension and adherent cells.
Researchers use this kit to detect apoptosis in cell populations after treatment with reagents of interest. The kit supports discrimination of cells at different apoptotic stages, which is not possible with a single stain. Cells can be classified as early apoptotic (Annexin V-positive only), necrotic or late apoptotic (Annexin V and DAPI double-positive), or naked nuclei (DAPI-positive only). A published example treats Jurkat cells with 5 µM Camptothecin for 4 h and analyzes the resulting populations.
The kit combines two labels. Annexin V is conjugated to PE/TR, and DAPI is a nuclear dye with a high DNA-binding constant that is efficiently excluded by intact cells. Due to loss of membrane integrity in late apoptotic or necrotic cells, DAPI enters the cell and stains DNA. Staining is performed in a one-step or two-step protocol with a 15 to 20 minute incubation at room temperature in the dark. The PE/TR signal is read at Ex/Em 495;565/620 nm, and results are acquired by flow cytometry or fluorescence microscopy.
The kit is designed for cells in suspension and adherent cells. Cell suspensions are washed with PBS, counted, and divided into tubes of 1 to 5 × 10^5 cells each. Adherent cells require particular care: suspension cells generated during apoptosis induction must be collected and analyzed together with the adherent cells. Mechanical damage during digestion should be minimized, and trypsin solutions should avoid EDTA, which interferes with Annexin V binding to phosphatidylserine. Stained samples should be analyzed promptly and protected from extended light exposure to prevent fluorophore quenching.
| Application: | Annexin V detection |
| Detection method: | Fluorometric |
| Sample type: | Cell samples (suspension and adherent) |
| Assay time: | 40 min |
| Detection instrument: | Flow cytometer; fluorescence microscope |
| Dye type: | PE/TR |
| Ex/Em: | 495;565/620 |
| Channel set: | ECD |
- Annexin V-PE/TR conjugate binds phosphatidylserine on the outer leaflet of apoptotic cells in a calcium-dependent manner
- DAPI included as a membrane-integrity counterstain to separate late apoptotic, necrotic, and nuclei-only populations
- Single-step and two-step staining protocols are provided.
- Assay time of 40 min; incubation at room temperature for 15-20 min in the dark
- Compatible with flow cytometry (ECD channel for PE/TR; DAPI preferably read in the Pacific Blue channel) and fluorescence microscopy
- Research Use Only
Annexin V binds phosphatidylserine (PS) in a calcium-dependent manner. The Annexin V-PE/TR conjugate binds specifically to PS on the outer leaflet of apoptotic cell membranes and can be detected by flow cytometry or fluorescence microscopy. DAPI has a high DNA binding constant and is excluded by intact cells; it enters cells that have lost membrane integrity (late apoptotic or necrotic cells) and stains DNA. Cells are classified as Annexin V single-positive (early apoptotic), Annexin V and DAPI double-positive (necrotic or late apoptotic), or DAPI single-positive (naked nuclei).
- Quantifying early apoptosis (Annexin V-positive, DAPI-negative cells) by flow cytometry
- Distinguishing early apoptotic, late apoptotic/necrotic, and nuclei-only populations in treated cell cultures
- Dead cell discrimination during flow cytometric analysis
- Visualizing PS exposure in apoptotic cells by fluorescence microscopy
| Component | Storage |
| Annexin V-PE/TR Reagent | 2-8°C, protect from light |
| Annexin V Binding Buffer (10×) | 2-8°C |
| DAPI Reagent (25 µg/mL) | 2-8°C or -20°C, protect from light |
- Phosphate-buffered saline (PBS)
- Deionized water (for diluting Annexin V Binding Buffer to 1×)
- Flow cytometer with ECD channel (and Pacific Blue channel for DAPI preferred) or fluorescence microscope
- Centrifuge capable of 300 ×g
- Microcentrifuge tubes or flow cytometry tubes
- Vortex mixer
- Pipettes and tips
- Calcium-containing buffer compatible with Annexin V binding (1× Annexin V Binding Buffer provided)
- Trypsin without EDTA for adherent cell harvesting (EDTA-containing trypsin should be avoided or thoroughly washed out)
Cells (suspension and adherent)
- Induce apoptosis of suspension cells with the reagents of interest. Collect the cell culture, centrifuge at 300 × g for 5 min, and discard the supernatant. Add PBS to wash the cells, resuspend gently, and count the cells.
- For adherent cells, collect the suspension cells generated after apoptosis induction and analyze them together with the subsequently collected adherent cells. Avoid mechanical damage during digestion. Use trypsin solution without EDTA where possible. If trypsin containing EDTA is used, wash the cells thoroughly after harvesting to remove EDTA.
- Prepare 1× Annexin V Binding Buffer by diluting Annexin V Binding Buffer (10×) with deionized water before use.
- One-step process: split the cell suspension into tubes at 1 to 5 × 10^5 cells per tube. Centrifuge at 300 × g for 5 min, discard the supernatant, and wash with PBS. Discard the supernatant and resuspend the cells in 500 µL of 1× Annexin V Binding Buffer.
- One-step process: add 5 µL of Annexin V-PE/TR and 5 µL of DAPI to each tube. Gently vortex and incubate at room temperature for 15 to 20 min in the dark. Analyze immediately, or place on ice in the dark and analyze within 1 h.
- Two-step process: split the cell suspension into tubes at 1 to 5 × 10^5 cells per tube. Centrifuge at 300 × g for 5 min, discard the supernatant, and wash with PBS. Discard the supernatant and resuspend the cells in 100 µL of 1× Annexin V Binding Buffer.
- Two-step process: add 2.5 µL of Annexin V-PE/TR and 2.5 µL of DAPI to each tube. Gently vortex and incubate at room temperature for 15 to 20 min in the dark.
- Two-step process: add 400 µL of 1× Annexin V Binding Buffer to the tube and mix gently. Analyze immediately, or place on ice in the dark and analyze within 1 h.
- Titrate the reagents for optimal performance in specific cell models. The two-step protocol allows half the reagent amount to give results of matched quality to the one-step protocol.
Reagent preparation
- Dilute Annexin V Binding Buffer (10×) with deionized water to 1× working buffer before use.
One-step process
- Induce apoptosis in cells with the reagents of interest. Collect cell cultures, centrifuge at 300 ×g for 5 min, and discard the supernatant. Wash cells with PBS, resuspend gently, and count cells.
- Split the cell suspension into tubes at 1-5×10^5 cells per tube. Centrifuge at 300 ×g for 5 min, discard the supernatant, wash with PBS, and discard the supernatant. Resuspend cells in 500 µL of 1× Annexin V Binding Buffer.
- Add 5 µL of Annexin V-PE/TR reagent and 5 µL of DAPI reagent to each tube.
- Gently vortex and incubate at room temperature for 15-20 min in the dark.
- Analyze cells immediately. Otherwise, place cells on ice in the dark and analyze within 1 h.
Two-step process
- Induce apoptosis in cells with the reagents of interest. Collect cell cultures, centrifuge at 300 ×g for 5 min, and discard the supernatant. Wash cells with PBS, resuspend gently, and count cells.
- Split the cell suspension into tubes at 1-5×10^5 cells per tube. Centrifuge at 300 ×g for 5 min, discard the supernatant, wash with PBS, and discard the supernatant. Resuspend cells in 100 µL of 1× Annexin V Binding Buffer.
- Add 2.5 µL of Annexin V-PE/TR reagent and 2.5 µL of DAPI reagent to each tube.
- Gently vortex and incubate at room temperature for 15-20 min in the dark.
- Add 400 µL of 1× Annexin V Binding Buffer to each tube and mix gently.
- Analyze cells immediately. Otherwise, place cells on ice in the dark and analyze within 1 h.
What sample types does the kit support?
The kit is designed to detect apoptosis in suspension cells and adherent cells. Its listed sample type is cells, and it is intended for flow cytometry or fluorescence microscopy.
How should the reagents be stored?
Store the kit at 2 to 8°C for 12 months, protected from light. Avoid freeze/thaw cycles of the reagents. Prepare 1× Annexin V Binding Buffer from the 10× concentrate with deionized water just before use.
Which instrument settings should be used?
Annexin V-PE/TR can be detected in the ECD channel, and the product page lists Ex/Em 495;565/620 nm. The DAPI channel is preferred to the Pacific Blue channel for DAPI detection.
What can interfere with Annexin V binding?
EDTA interferes with Annexin V binding to phosphatidylserine, so trypsin solutions should avoid EDTA where possible. If EDTA-containing trypsin is used, wash the cells thoroughly after harvesting to remove it.
How long does the assay take, and when should samples be analyzed?
The listed assay time is 40 min, including a 15 to 20 min room-temperature incubation in the dark. Analyze cells immediately after staining, or keep them on ice in the dark and analyze within 1 h.
| Storage: | 2-8°C for 12 months, protect from light |
| Freeze/thaw: | Avoid freeze/thaw cycles |
| Expiration: | 12 months |
| Shipping: | Ice bag |
Cautions
- For Research Use Only. Not for use in diagnostic or therapeutic procedures.
- When detecting adherent cells, collect the suspension cells generated after apoptosis induction and analyze them together with the adherent cells.
- Minimize mechanical damage during adherent cell digestion.
- Avoid EDTA-containing trypsin; EDTA interferes with Annexin V binding to phosphatidylserine. If EDTA-containing trypsin is used, wash cells thoroughly after harvesting.
- Analyze samples as soon as possible after staining to avoid an increase in apoptotic or necrotic signal.
- Avoid extended exposure of samples to direct light to protect fluorophores from quenching.
- Wear a lab coat and disposable gloves during experiments.
