Product Name:	Human Teratocarcinoma-derived growth factor 1 (TDGF1) ELISA Kit
SKU:	HUEB1144
Size:	96T
Target:	Human Teratocarcinoma-derived growth factor 1 (TDGF1)
Synonyms:	Cripto-1 growth factor, Epidermal growth factor-like cripto protein CR1, CRGF, CRIPTO
Assay Type:	Sandwich
Detection Method:	ELISA
Reactivity:	Human
Detection Range:	62.5-4000pg/mL
Sensitivity:	21.8pg/mL

Intra CV:

4.6%

Inter CV:

7.3%

Linearity:

Sample	1:2	1:4	1:8	1:16
Serum(N=5)	114-124%	85-95%	91-103%	105-115%
EDTA Plasma(N=5)	108-116%	104-114%	91-100%	90-90%
Heparin Plasma(N=5)	84-96%	91-101%	117-127%	94-104%

Recovery:

Sample Type	Average(%)	Recovery Range(%)
Serum	93	87-99
Plasma	95	89-101

Function:

Could play a role in the determination of the epiblastic cells that subsequently give rise to the mesoderm.

Uniprot:	P13385
Sample Type:	Serum, plasma, tissue homogenates, cell culture supernates and other biological fluids
Specificity:	Natural and recombinant human Teratocarcinoma-derived growth factor 1
Sub Unit:	Interacts with the activin type-1 receptor ACVR1B.
Research Area:	Cancer
Subcellular Location:	Cell membrane Lipid-anchor GPI-anchor
Storage:	Please see kit components below for exact storage details
Note:	For research use only

UniProt Protein Function:	TDGF1: Could play a role in the determination of the epiblastic cells that subsequently give rise to the mesoderm. Interacts with the activin type-1 receptor ACVR1B. Preferentially expressed in gastric and colorectal carcinomas than in their normal counterparts. Expressed in breast and lung.
UniProt Protein Details:	Protein type:Membrane protein, GPI anchor; Membrane protein, peripheral; Motility/polarity/chemotaxis; Cell adhesion; Cell cycle regulation Chromosomal Location of Human Ortholog: 3p21.31 Cellular Component: extrinsic to plasma membrane; Golgi apparatus; extracellular space; cell surface; perinuclear region of cytoplasm; apical plasma membrane; plasma membrane; nucleus; lipid raft Molecular Function:protein binding; growth factor activity; receptor binding Biological Process: activation of MAPK activity; somatic stem cell maintenance; heart development; regulation of signal transduction; gastrulation; Wnt receptor signaling pathway through beta-catenin; cardiac muscle cell differentiation; BMP signaling pathway; positive regulation of fibroblast proliferation; mammary gland development; determination of anterior/posterior axis, embryo; positive regulation of cell proliferation; vasculogenesis; positive regulation of cell-matrix adhesion; cell differentiation; epidermal growth factor receptor signaling pathway; in utero embryonic development; morphogenesis of a branching structure; embryonic development; peptidyl-serine phosphorylation; positive regulation of peptidyl-tyrosine phosphorylation; cell migration during sprouting angiogenesis; positive regulation of transcription from RNA polymerase II promoter; negative regulation of transforming growth factor beta receptor signaling pathway; negative regulation of apoptosis; positive regulation of cell migration
NCBI Summary:	This gene encodes an epidermal growth factor-related protein that contains a cripto, FRL-1, and cryptic domain. The encoded protein is an extracellular, membrane-bound signaling protein that plays an essential role in embryonic development and tumor growth. Mutations in this gene are associated with forebrain defects. Pseudogenes of this gene are found on chromosomes 2, 3, 6, 8, 19 and X. Alternate splicing results in multiple transcript variants. [provided by RefSeq, Mar 2010]
UniProt Code:	P13385
NCBI GenInfo Identifier:	117473
NCBI Gene ID:	6997
NCBI Accession:	P13385.1
UniProt Secondary Accession:	P13385,Q8TCC1,
UniProt Related Accession:	P13385
Molecular Weight:	21,169 Da
NCBI Full Name:	Teratocarcinoma-derived growth factor 1
NCBI Synonym Full Names:	teratocarcinoma-derived growth factor 1
NCBI Official Symbol:	TDGF1
NCBI Official Synonym Symbols:	CR; CRGF; CRIPTO
NCBI Protein Information:	teratocarcinoma-derived growth factor 1
UniProt Protein Name:	Teratocarcinoma-derived growth factor 1
UniProt Synonym Protein Names:	Cripto-1 growth factor; CRGF; Epidermal growth factor-like cripto protein CR1
Protein Family:	Teratocarcinoma-derived growth factor
UniProt Gene Name:	TDGF1
UniProt Entry Name:	TDGF1_HUMAN

Component	Quantity (96 Assays)	Storage
ELISA Microplate (Dismountable)	8×12 strips	-20°C
Lyophilized Standard	2	-20°C
Sample Diluent	20ml	-20°C
Assay Diluent A	10mL	-20°C
Assay Diluent B	10mL	-20°C
Detection Reagent A	120µL	-20°C
Detection Reagent B	120µL	-20°C
Wash Buffer	30mL	4°C
Substrate	10mL	4°C
Stop Solution	10mL	4°C
Plate Sealer	5	-

Other materials and equipment required:

Microplate reader with 450 nm wavelength filter
Multichannel Pipette, Pipette, microcentrifuge tubes and disposable pipette tips
Incubator
Deionized or distilled water
Absorbent paper
Buffer resevoir

*Note: The below protocol is a sample protocol. Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.

Allow all reagents to reach room temperature (Please do not dissolve the reagents at 37°C directly). All the reagents should be mixed thoroughly by gently swirling before pipetting. Avoid foaming. Keep appropriate numbers of strips for 1 experiment and remove extra strips from microtiter plate. Removed strips should be resealed and stored at -20°C until the kits expiry date. Prepare all reagents, working standards and samples as directed in the previous sections. Please predict the concentration before assaying. If values for these are not within the range of the standard curve, users must determine the optimal sample dilutions for their experiments. We recommend running all samples in duplicate.

Step
1.	Add Sample: Add 100µL of Standard, Blank, or Sample per well. The blank well is added with Sample diluent. Solutions are added to the bottom of micro ELISA plate well, avoid inside wall touching and foaming as possible. Mix it gently. Cover the plate with sealer we provided. Incubate for 120 minutes at 37°C.
2.	Remove the liquid from each well, don't wash. Add 100µL of Detection Reagent A working solution to each well. Cover with the Plate sealer. Gently tap the plate to ensure thorough mixing. Incubate for 1 hour at 37°C. Note: if Detection Reagent A appears cloudy warm to room temperature until solution is uniform.
3.	Aspirate each well and wash, repeating the process three times. Wash by filling each well with Wash Buffer (approximately 400µL) (a squirt bottle, multi-channel pipette,manifold dispenser or automated washer are needed). Complete removal of liquid at each step is essential. After the last wash, completely remove remaining Wash Buffer by aspirating or decanting. Invert the plate and pat it against thick clean absorbent paper.
4.	Add 100µL of Detection Reagent B working solution to each well. Cover with the Plate sealer. Incubate for 60 minutes at 37°C.
5.	Repeat the wash process for five times as conducted in step 3.
6.	Add 90µL of Substrate Solution to each well. Cover with a new Plate sealer and incubate for 10-20 minutes at 37°C. Protect the plate from light. The reaction time can be shortened or extended according to the actual color change, but this should not exceed more than 30 minutes. When apparent gradient appears in standard wells, user should terminatethe reaction.
7.	Add 50µL of Stop Solution to each well. If color change does not appear uniform, gently tap the plate to ensure thorough mixing.
8.	Determine the optical density (OD value) of each well at once, using a micro-plate reader set to 450 nm. User should open the micro-plate reader in advance, preheat the instrument, and set the testing parameters.
9.	After experiment, store all reagents according to the specified storage temperature respectively until their expiry.

When carrying out an ELISA assay it is important to prepare your samples in order to achieve the best possible results. Below we have a list of procedures for the preparation of samples for different sample types.

Sample Type	Protocol
Serum	If using serum separator tubes, allow samples to clot for 30 minutes at room temperature. Centrifuge for 10 minutes at 1,000x g. Collect the serum fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. If serum separator tubes are not being used, allow samples to clot overnight at 2-8°C. Centrifuge for 10 minutes at 1,000x g. Remove serum and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
Plasma	Collect plasma using EDTA or heparin as an anticoagulant. Centrifuge samples at 4°C for 15 mins at 1000 × g within 30 mins of collection. Collect the plasma fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. Note: Over haemolysed samples are not suitable for use with this kit.
Urine & Cerebrospinal Fluid	Collect the urine (mid-stream) in a sterile container, centrifuge for 20 mins at 2000-3000 rpm. Remove supernatant and assay immediately. If any precipitation is detected, repeat the centrifugation step. A similar protocol can be used for cerebrospinal fluid.
Cell culture supernatant	Collect the cell culture media by pipette, followed by centrifugation at 4°C for 20 mins at 1500 rpm. Collect the clear supernatant and assay immediately.
Cell lysates	Solubilize cells in lysis buffer and allow to sit on ice for 30 minutes. Centrifuge tubes at 14,000 x g for 5 minutes to remove insoluble material. Aliquot the supernatant into a new tube and discard the remaining whole cell extract. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Tissue homogenates	The preparation of tissue homogenates will vary depending upon tissue type. Rinse tissue with 1X PBS to remove excess blood & homogenize in 20ml of 1X PBS (including protease inhibitors) and store overnight at ≤ -20°C. Two freeze-thaw cycles are required to break the cell membranes. To further disrupt the cell membranes you can sonicate the samples. Centrifuge homogenates for 5 mins at 5000xg. Remove the supernatant and assay immediately or aliquot and store at -20°C or -80°C.
Tissue lysates	Rinse tissue with PBS, cut into 1-2 mm pieces, and homogenize with a tissue homogenizer in PBS. Add an equal volume of RIPA buffer containing protease inhibitors and lyse tissues at room temperature for 30 minutes with gentle agitation. Centrifuge to remove debris. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Breast Milk	Collect milk samples and centrifuge at 10,000 x g for 60 min at 4°C. Aliquot the supernatant and assay. For long term use, store samples at -80°C. Minimize freeze/thaw cycles.
