High mobility group protein B1 (HMGB1) is a member of the High Mobility Group-box superfamily. HMGB1 serves as a multifunctional redox sensitive protein with diverse functions in several cellular compartments, including inflammation, cell differentiation, and tumor cell migration. In the nucleus, HMGB1 is one of the main chromatin-associated non-histone proteins and serves as a DNA chaperone involved in replication, transcription, chromatin remodeling, V(D)J recombination, DNA repair, and genome stability. HMGB1 is a sensor and/or chaperone in the cytoplasm that activates TLR9-mediated immune responses and moderates autophagy. HMGB1 has also been shown to act as a danger associated molecular pattern (DAMP) molecule, which enhances the immune response during tissue injury. HMGB1 is believed to play a role in the development of several chronic inflammatory and autoimmune diseases, as well as cancer. High levels of serum HMGB1 have been detected in a number of inflammatory diseases, including sepsis, rheumatoid arthritis, artherosclerosis, chronic kidney disease, and systemic lupus erythematosus (SLE). HMGB1 has also been linked to diabetes and Alzheimer's disease.
Human HMGB1 ELISA Kit
HMGB1, High mobility group protein B1, HMG-1, HMG1, HMG3, SBP-1, Amphoterin, high mobility group box 1, High mobility group protein 1, high-mobility group, nonhistone chromosomal protein 1, high-mobility group box 1, Sulfoglucuronyl carbohydRate binding protein
Sandwich ELISA, Double Antibody
This ELISA kit allows for the in vitro quantitative determination of Human HMGB1 concentrations in serum plasma and other biological fluids.
4°C for 6 months
For Research Use Only
Matrices listed below were spiked with certain level of Human HMGB1 and the recovery rates were calculated by comparing the measured value to the expected amount of Human HMGB1 in samples.
The linearity of the kit was assayed by testing samples spiked with appropriate concentration of Human HMGB1 and their serial dilutions. The results were demonstrated by the percentage of calculated concentration to the expected.
Intra-Assay: CV<8% Inter-Assay: CV<10%
ELISA Microplate (Dismountable)
4°C for 6 months
Sample/Standard Dilution Buffer
4°C (Protect from light)
Antibody Dilution Buffer
4°C (Protect from light)
SABC Dilution Buffer
4°C (Protect from light)
Other materials and equipment required:
Microplate reader with 450 nm wavelength filter
Multichannel Pipette, Pipette, microcentrifuge tubes and disposable pipette tips
*Note: Protocols are specific to each batch/lot. For the correct instructions please follow the protocol included in your kit.
Before adding to wells, equilibrate the SABC working solution and TMB substrate for at least 30 min at 37°C. When diluting samples and reagents, they must be mixed completely and evenly. It is recommended to plot a standard curve for each test.
Set standard, test sample and control (zero) wells on the pre-coated plate respectively, and then, record their positions. It is recommended to measure each standard and sample in duplicate. Wash plate 2 times before adding standard, sample and control (zero) wells!
Aliquot 0.1ml standard solutions into the standard wells.
Add 0.1 ml of Sample / Standard dilution buffer into the control (zero) well.
Add 0.1 ml of properly diluted sample ( Human serum, plasma, tissue homogenates and other biological fluids.) into test sample wells.
Seal the plate with a cover and incubate at 37 °C for 90 min.
Remove the cover and discard the plate content, clap the plate on the absorbent filter papers or other absorbent material. Do NOT let the wells completely dry at any time. Wash plate X2.
Add 0.1 ml of Biotin- detection antibody working solution into the above wells (standard, test sample & zero wells). Add the solution at the bottom of each well without touching the side wall.
Seal the plate with a cover and incubate at 37°C for 60 min.
Remove the cover, and wash plate 3 times with Wash buffer. Let wash buffer rest in wells for 1 min between each wash.
Add 0.1 ml of SABC working solution into each well, cover the plate and incubate at 37°C for 30 min.
Remove the cover and wash plate 5 times with Wash buffer, and each time let the wash buffer stay in the wells for 1-2 min.
Add 90 µl of TMB substrate into each well, cover the plate and incubate at 37°C in dark within 10-20 min. (Note: This incubation time is for reference use only, the optimal time should be determined by end user.) And the shades of blue can be seen in the first 3-4 wells (with most concentrated standard solutions), the other wells show no obvious color.
Add 50 µl of Stop solution into each well and mix thoroughly. The color changes into yellow immediately.
Read the O.D. absorbance at 450 nm in a microplate reader immediately after adding the stop solution.
When carrying out an ELISA assay it is important to prepare your samples in order to achieve the best possible results. Below we have a list of procedures for the preparation of samples for different sample types.
If using serum separator tubes, allow samples to clot for 30 minutes at room temperature. Centrifuge for 10 minutes at 1,000x g. Collect the serum fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
If serum separator tubes are not being used, allow samples to clot overnight at 2-8°C. Centrifuge for 10 minutes at 1,000x g. Remove serum and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles.
Collect plasma using EDTA or heparin as an anticoagulant. Centrifuge samples at 4°C for 15 mins at 1000 × g within 30 mins of collection. Collect the plasma fraction and assay promptly or aliquot and store the samples at -80°C. Avoid multiple freeze-thaw cycles. Note: Over haemolysed samples are not suitable for use with this kit.
Urine & Cerebrospinal Fluid
Collect the urine (mid-stream) in a sterile container, centrifuge for 20 mins at 2000-3000 rpm. Remove supernatant and assay immediately. If any precipitation is detected, repeat the centrifugation step. A similar protocol can be used for cerebrospinal fluid.
Cell culture supernatant
Collect the cell culture media by pipette, followed by centrifugation at 4°C for 20 mins at 1500 rpm. Collect the clear supernatant and assay immediately.
Solubilize cells in lysis buffer and allow to sit on ice for 30 minutes. Centrifuge tubes at 14,000 x g for 5 minutes to remove insoluble material. Aliquot the supernatant into a new tube and discard the remaining whole cell extract. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
The preparation of tissue homogenates will vary depending upon tissue type. Rinse tissue with 1X PBS to remove excess blood & homogenize in 20ml of 1X PBS (including protease inhibitors) and store overnight at ≤ -20°C. Two freeze-thaw cycles are required to break the cell membranes. To further disrupt the cell membranes you can sonicate the samples. Centrifuge homogenates for 5 mins at 5000xg. Remove the supernatant and assay immediately or aliquot and store at -20°C or -80°C.
Rinse tissue with PBS, cut into 1-2 mm pieces, and homogenize with a tissue homogenizer in PBS. Add an equal volume of RIPA buffer containing protease inhibitors and lyse tissues at room temperature for 30 minutes with gentle agitation. Centrifuge to remove debris. Quantify total protein concentration using a total protein assay. Assay immediately or aliquot and store at ≤ -20 °C.
Collect milk samples and centrifuge at 10,000 x g for 60 min at 4°C. Aliquot the supernatant and assay. For long term use, store samples at -80°C. Minimize freeze/thaw cycles.
